JC25 Type Cold Cutting Saw

cutting range

Round tube：MAX38mm

thickness：0.5～1.5mm

Square tube：MAX30×30mm

thickness：0.5～1.5mm

Rectangular tube：MAX 20×40mm

thickness：0.5～1.5mm

Maximum production speed

140-150m/min (when the cut length is 6 meters, the pipe diameter is ≤19mm, and the wall thickness is ≤0.7mm)

Height from the bottom surface to the rolling bottom line：

702mm

Mechanical length of cold cutting saw

4020*1080*1280mm (subject to the final drawing)

Motor configuration

Drive motor: 4.4KW

Yaskawa servo motor

Feed motor: 1.3KW

Yaskawa servo motor

Saw blade motor: 2.9KW

Yaskawa servo motor

linear guide rail

Adopted: Taiwan HIWIN 35-type guide rail

Transmission mode

Adopting: gear and rack

Drive servo driver

Yaskawa 4.4KW servo driver

Feed servo driver

Yaskawa 1.3KW servo driver

Saw blade motor driver

Yaskawa 3.0KW servo driver

Touch Screen

Kinco 10-inch screen
